SCHNEIDER 140NOE77101140NOE77101 is an Ethernet communication module for Schneider Electric’s Modicon Quantum series PLC. It is mainly used to connect the PLC to the Ethernet network to realize the communication between the PLC and other devices or systems. Through this module, you can implement a variety of industrial communication protocols such as Modbus TCP/IP, OPC UA, and facilitate data exchange and remote monitoring.
​Product parameters and specifications:
​Interface type: Ethernet 10/100Base-T, 100Base-FX
Communication protocols: Modbus TCP/IP, OPC UA, etc
Power supply voltage: 5VDC
Current: 750mA
Protection level: IP20
Installation method: guide rail installation
Other features: Transparent ready, data editor, rack viewer, etc
Main functions:
​PLC and Ethernet connection: Provides a physical connection between a PLC and an Ethernet.
Data transmission: Realize the data exchange between PLC and other equipment.
Remote monitoring: Support remote access and monitoring PLC.
Network configuration: Provides rich network configuration functions.
Application field:
​Industrial automation

Building automation
Process control
Data acquisition
Note:
​The module has been discontinued and Schneider Electric is no longer accepting new orde

rs.
The 140NOE77101 has been replaced by an Ethernet 100Mbps multimode fiber port.
