SCHNEIDER 140XBP01600

The Schneider Electric 140XBP01600 module is one of the core components of the Modicon Quantum series PLC, it is a backplane used to connect and support other modules in the PLC rack, such as CPU modules, I/O modules, etc. The backplane provides communication and power connections between modules and is the backbone of the entire PLC system.

Product parameters and specifications
Number of slots: 16

Installation method: Screw fixation
Dimensions: 26.4 inches x 11.4 inches

Material: Metal
Certification: CE certification
Main function
Module connection: Provides physical interfaces to connect various modules in the PLC rack.
Signal transmission: transmission of control signals, data signals and power signals.
System support: Provide structural support for the whole PLC system.
Application field
Industrial automation: widely used in various industrial automation systems, such as manufacturing, process industry, etc.
Machine control: Used to control various types of machines and equipment.
Data acquisition: provides a platform for data acquisition system.
Product advantage
High reliability: The use of high-quality materials and processes to ensure long-term stable operation.
Good compatibility: Compatible with other modules in the Modicon Quantum family.
Strong scalability: The 16-slot design provides enough room for expansion.
Matters needing attention
Installation: It must be properly installed according to the instructions to ensure that the modules are tightly connected.
Grounding: Good grounding must be ensured to prevent interference.
Maintenance: Periodically check the backplane to ensure reliable connection.
