SCHNEIDER 140XTS00100

The Schneider Electric 140XTS00100 is an I/O connection module designed for the Modicon Quantum family of programmable logic controllers (PLCS). It is mainly used to connect various types of I/O modules, such as digital input/output modules, analog input/output modules, etc., so as to expand the input and output points of PLC and achieve more complex control functions.

Product parameters and specifications
Model: 140XTS00100
Type: I/O connection module
Number of terminals: 40
Protection level: IP20
Mounting method: DIN rail mounting
Compatibility: Modicon Quantum series PLC
Main feature

Connection extension: Additional I/O connection points for Modicon Quantum PLC.
Modular design: Easy and flexible expansion of I/O points.
High reliability: Industrial grade design, suitable for harsh industrial environment.
Easy installation: DIN rail installation is convenient and fast.
Main function
Provide physical connection: Realize the connection between the I/O module and the PLC.
Signal transmission: transmission of digital signals and analog signals.
Application scenario
Schneider 140XTS00100 is mainly used in automated control systems that requ

ire extended I/O points, such as:

Process control: acquisition of process variables, control of actuators.
Machine control: Control of machine movement, speed and position.
Automatic production line control: control of various equipment on the production line.
Matters needing attention
Compatibility: Make sure that the I/O module used is compatible with 140XTS00100.
Installation: Install correctly according to the instructions to ensure reliable connection.
Maintenance: Check the module regularly to avoid damage.
