SCHNEIDER BMXXEM010

The Schneider Electric BMXXEM010 module is an analog input module for the Modicon M340 series PLC. It is mainly used to convert external analog signals (such as temperature, pressure, flow, etc.) into digital signals that can be recognized by PLC, so as to realize the acquisition and control of analog quantities.

Product parameters and specifications
Model: BMXXEM010
Series: Modicon M340

Function: analog input module
Input channels: 4
Input type: High
Input range: Depending on the model and configuration (usually 0-10V or 4-20mA)
Resolution: Depends on the model and configuration
Isolation: Channels are isolated from each other
Mounting method: DIN rail mounting
Protection level: Depending on the specific model and application environment

Size: According to the specific model
Note: The above parameters are only based on the model BMXXEM010. For specific parameters, please refer to the official product documentation of Schneider Electric.

Product characteristics
High precision: Provides high precision analog measurement
Multi-channel: Supports multi-channel simultaneous sampling
Isolation design: Each channel is isolated from each other to improve anti-interference ability
Flexible configuration: Software can be used for flexible configuration
High reliability: Industrial grade design, suitable for harsh environments
Product function
Analog data acquisition: converts external analog signals into digital signals
Data transmission: The collected data is transmitted to the PLC
