SCHNEIDER TSXDMF342A

The Schneider Electric TSXDMF342A is an analog input module designed for Modicon PLCS. It is mainly used to convert analog signals from the field (such as temperature, pressure, flow, etc.) into digital signals that can be recognized by the PLC for further processing and control by the PLC. The module usually has multiple independent analog input channels, which can simultaneously collect multiple analog signals.
​Product parameters and specifications (typical values, refer to the product manual)
Number of channels: Generally 4 channels or 8 channels, depending on the model
Input type: Analog voltage or current
Input range: configurable, such as 0-10V, 4-20mA, etc
Resolution: High resolution to ensure measurement accuracy
Sampling rate: Configurable and supports multiple sampling rates
Isolation: Channels are isolated from each other
Power supply: 24V DC
Operating temperature: 0°C ~ 55°C

Mounting method: DIN rail mounting
peculiarity
High-precision measurement: Using high-precision A/D converter to ensure accurate and reliable measurement results.
Multi-channel design: A module can simultaneously collect analog signals from multiple channels.

Flexible configuration: Supports a variety of input ranges and sampling rates, and can be configured as required.
Isolation design: Each channel is isolated from each other, which improves the anti-interference ability of the system.
Easy to use: Seamless integration with Modicon PLC and simple configuration.
