Schneider TSXP572634

The Schneider Electric Modicon TSXP572634 module is an extended I/O module manufactu

red by Schneider Electric for the Modicon Modicon M340 control system. The module has the following features:

32 digital input/output channels
Supports multiple I/O types, including switching, analog, and serial
Can be used with other Modicon Modicon M340 modules
Product parameters:

Number of channels: 32
I/O type: digital, analog, serial port
Voltage range: 24 VDC
Current range: 2 A
Communication interface: Modbus RTU
Power supply voltage: 24 VDC
Power consumption: Typical value 5 W, maximum 10 W
Operating temperature: -20°C to +55°C
Storage temperature: -40°C to +80°C
Humidity: 5% to 95% (non-condensing)
Specifications:

Dimensions: 125 mm x 75 mm x 30 mm (4.92 in. x 2.95 in. x 1.18 in.)
Weight: 500 g (1.10 lb)
Protection level: IP67
Application field:

The Schneider Electric Modicon TSXP572634 module is used in a wide range of industrial automation applications, including:

Discrete manufacturing
Process manufacturing
Packaging machinery
Automobile manufacturing
