SCHNEIDER TSXSAY1000

The Schneider TSXSAY1000 module is an AS-Interface master station module from Schneider Electric designed for the Modicon Premium automation platform. It is mainly used to connect the slave station equipment (such AS sensors and actuators) on the AS-I bus to the PLC to achieve automatic control.

Product name

Chinese name: Schneider Modicon Premium AS-Interface master station module
English name: Schneider Electric TSXSAY1000 AS-Interface master module

Product description
AS the master station of the AS-I bus, the TSXSAY1000 module is responsible for controlling and managing the slave station devices connected to the bus. It can realize the configuration, data reading and writing and diagnosis of the slave station. The module has the characteristics of compact structure, easy installation, flexible configuration, etc., and is widely used in industrial production lines with high degree of automation.

Main feature
AS-i bus interface: Supports the AS-i bus protocol and can be connected to a variety of AS-i slave devices.
Flexible configuration: Parameters such as slave address and input/output type can be configured.
Diagnostic function: Provides a powerful diagnostic function to facilitate troubleshooting.
Easy integration: Seamless integration with Modicon Premium PLC.
Product parameters (part)
Power supply voltage: 5V DC
Maximum current: 450mA
Number of slave stations: Up to 62 discrete I/O slaves, or up to 31 analog I/O slaves
Communication rate: Standard AS-i rate
