SCHNEIDER XBTGK2330

The Schneider Electric XBTGK2330 is a powerful graphical operating panel that belongs to the Magelis HMI product family. It is widely used in the field of industrial automation for human-computer interaction interfaces to provide intuitive and friendly operation methods to help operators monitor and control industrial processes. The XBTGK2330 features a high-resolution color touch screen, supports multiple languages, and displays rich graphics and animations to provide users with an intuitive operating experience.

Product parameters and specifications (specific parameters may vary depending on the model and configuration, please refer to the official data)
Type: Graphical operation panel

Display: high resolution color touch screen
Size: Depending on the model (4.3 inches, 7 inches, etc.)
Resolution: High resolution, providing a clear image display

Interface: Support a variety of communication interfaces, such as Ethernet, RS232 and so on
Storage: With internal memory, can store programs, pictures and other data
Protection Class: IP65 (normal), suitable for industrial environment
Power supply: 24V DC
Main function
Man-machine interaction: provides an intuitive user interface to facilitate the operator’s man-machine interaction.
Data display: display process variables, alarm information, equipment status, etc.
Trend chart: Shows the trend of process variables over time.
