SMC AR40-03BE
The SMC AR40-03BE is a high performance modular pressure regulator manufactured by SMC. It is mainly used in pneumatic systems to accurately regulate the pressure of compressed air. The series of products are widely used in various industrial automation equipment because of its compact structure, high adjustment precision and fast response speed.
Product parameters and specifications
Parameter Name Parameter Value Unit description
Model AR40-03BE Product model
Connection Mode G1/4 Air inlet and outlet connection mode
Adjustable range 0.05 to 0.7 MPa Indicates the adjustable output pressure
range of the MPa
The flow coefficient 0.4 indicates the flow characteristic of the regulator
Material Brass, stainless steel main material
Operating Temperature 5 to 60 ° C Indicates the applicable operating temperature range
Working pressure 0.1 to 0.7 MPa Rated working pressure of MPa
Export to Google Forms
Product characteristics
Modular design: Compact, easy to install and maintain.
High precision regulation: enables precise pressure control.
Fast response speed: rapid response to pressure changes.
Strong durability: the use of high-quality materials, corrosion resistance, long life.
