TRICONEX 5481

The TRICONEX 5481 is a safety analog input/output module for the TRICONEX safety platform. It is designed to provide reliable and secure analog input and output functions for security systems, enabling two-way analog communication between security systems and field devices.

The TRICONEX 5481 features eight analog input channels and eight analog output channels that support multiple signal types, including current and voltage. It also has a redundant design that ensures continued operation even if a single component fails.

The TRICONEX 5481 meets IEC 61508 safety standards and is SIL 2 certified. It also has high precision and low noise to meet the needs of critical safety systems.

Product characteristics

8 analog input channels
8 analog output channels

Supports multiple signal types: current, voltage
Redundant design ensures continued operation even if a single component fails
Meets IEC 61508 safety standards and is SIL 2 certified
High precision
Low noise
Product parameter

Number of input channels: 8 analog input channels
Number of output channels: 8 analog output channels
Supported signal types: current, voltage
Input range: 4mA to 20mA, -10V to 10V
Output range: 4mA to 20mA, -10V to 10V
Accuracy: ±0.1%
Noise: <0.2%
Product specification

Dimensions: 3U High x 1HP wide x 200 mm deep
Weight: About 2.5kg
Power supply: 24V DC
Application field

Oil and gas
chemicals
electricity
steel
CARS
