TRICONEX 8301A

The TRICONEX 8301A has a redundant design that includes two separate power inputs and two separate power outputs. It also has high efficiency and low power consumption to provide a reliable, stable power supply for safety systems.

The TRICONEX 8301A meets IEC 61508 safety standards and is SIL 2 certified. It also has a variety of protection features to ensure the safety of the power supply of the safety system.

Product characteristics

Redundant design: two independent power inputs and two independent power outputs

High efficiency
Low power consumption

Meets IEC 61508 safety standards and is SIL 2 certified
Multiple protection functions
Product parameter

Input voltage: 100V to 240V AC
Output voltage: 24V DC
Output current: 20A
Efficiency: >90%
Power factor: >0.9
Power consumption: <50W
Protection function: over voltage protection, over current protection, short circuit protection, under voltage protection
Product specification

Dimensions: 3U High x 1HP wide x 200 mm deep
Weight: about 3 kg
Operating temperature: -20°C to 60°C
Storage temperature: -40°C to 85°C
