TRICONEX 9566-810

The TRICONEX 9566-810 module is an integral part of the Triconex Safety Instrumentation System (SIS) to provide safety-critical digital output signals. The module adopts redundant design to ensure the reliability and availability of the system.

The 9566-810 module is suitable for a variety of security applications that require high reliability and availability, such as:

Oil and gas
chemicals
electricity

Nuclear industry
transportation
Product parameters:

Module type: digital output module
Number of channels: 8
Signal type: digital quantity
Output voltage range: 24V DC
Output current: 2A
Response time: <10 microseconds
Power consumption: <5 watts
Operating temperature: -40°C to +70°C
Protection level: IP67
Specifications:

Module size: 97 x 36 x 70 mm
Weight: 570 grams
Material: Aluminum alloy, PCB board, electronic components
Applications:

Safety control system
Emergency Shutdown System (ESD)
Fire Alarm System (FAS)
