woodward 8200-1302

The Woodward 8200-1302 module is a digital governor for the control of steam turbines and belongs to the Woodward 505D series. The module integrates graphical human-machine interface (HMI), has advanced control algorithm and rich communication functions, and is mainly used for steam turbine control in industrial field.

Product description

Features:
Speed control: high precision control of steam turbine speed to ensure stable operation of the system.
Protection function: Provides a variety of protection functions, such as over-speed protection, underspeed protection, etc., to ensure device safety.
Data monitoring: real-time monitoring of various operating parameters, and provide intuitive display.
Man-machine interaction: allows you to configure, monitor, and operate devices through graphical interfaces.

Applications:
Steam turbine: mainly used to control various types of steam turbines, such as industrial steam turbines, power generation steam turbines, etc.
Industrial automation: Widely used in industrial automation systems that require precise control of steam turbines.
Main parameters and specifications
Power Supply: 18-36 VDC
Display: 8.4-inch LCD
Communication: Modbus
Input: analog input, digital input
Output: analog output, relay output
Environmental conditions: Wide temperature range, strong anti-interference ability
Product characteristics
Integration: Integrated graphical interface, control algorithm and communication functions, easy to use.
Intelligent: The use of advanced control algorithm, with adaptive adjustment function.
High reliability: The design meets industry standards and has high reliability.
Scalability: It can be connected to other devices through communication protocols such as Modbus.
