WOODWARD 3522-1005

The Woodward 3522-1005 module is a drive module manufactured by Woodward for the control of electric actuators (such as EM-80/EM-300). It plays an important role in the control system of turbines, pumps, compressors and other equipment, and regulates the operating state of the equipment by driving the actuator.

Product name resolution

Woodward: Company name, is a global leader in control solutions.
3522-1005: Product model, used to distinguish between different models of products.
Product description
The 3522-1005 module is usually used in conjunction with Woodward’s electric actuators to receive control signals from controllers (such as PLCS, DCS), convert analog signals into power signals, and drive actuators for precise displacement control. The module has the following features:

High precision: It can achieve precise control of the actuator.

High reliability: Designed for industrial environments with high reliability.
Easy to install: Compact and easy to install.
Strong compatibility: can be used with various types of electric actuators.
