WOODWARD 8237-1246

The Woodward 8237-1246 module is part of the Woodward ProTech-GII family and is primarily used to detect and prevent turbine overspeed. Once the speed is detected to exceed the safety limit, the module sends a signal to trigger safety protection measures to prevent damage to the equipment. It is widely used in hydraulic, steam and gas turbines.

Product parameters and specifications (partial, detailed parameters please refer to the official data manual)
Model: 8237-1246
Function: overspeed protection

Output: Three independent non-voting trip relay outputs
Input: 4-20mA speed reading
Power Supply: Low and high voltage power input options
Temperature range: Operating temperature -4 to 140 degrees Fahrenheit, storage temperature -4 to 158 degrees Fahrenheit
Features: Three-module design, 2/3 voting structure, can be routinely tested
Main feature
High reliability: Three-module design, 2/3 voting structure, to ensure system reliability.
High sensitivity: can quickly detect the overspeed situation, timely trigger protection measures.
Strong anti-interference ability: It has the ability to resist sulfur, H2S and SO2 gas.
Easy installation: Wall mount and panel mount options are available.

Application field
Hydroelectric power: over-speed protection of water turbines
Thermal power generation: overspeed protection of steam and gas turbines
