PROSOFT MVI56-MCMR
The ProSoft Technology MVI56-MCMR is a Modbus Master/Slave communication module designed for Rockwell Automation ControlLogix systems. It allows ControlLogix processors to interface with devices using the Modbus RTU/ASCII serial communication protocol. This module acts as an input/output module on the ControlLogix backplane, making Modbus data appear as I/O data to the processor. It utilizes a reduced Input/Output (I/O) data block, making it suitable for remote rack applications over ControlNet™.
Product Parameters:
- Compatibility: Rockwell Automation ControlLogix platform
- Backplane Compatibility: Single slot – 1756 ControlLogix backplane compatible
- Current Draw: 800 mA @ 5 V DC, 3 mA @ 24 V DC
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
- Relative Humidity: 5% 1 to 95% non-condensing
1. detail.1688.com
- Serial Ports: 2 independently programmable serial interfaces (RS-232, RS-422, RS-485 selectable via jumpers)
- Baud Rate: 110 to 115,200 bps
- Data Memory Mapping: User-definable up to 5000 16-bit registers
- Backplane Isolation: 1000V Modbus-ControlLogix backplane isolation
