WESTINGHOUSE 1C31197G01

Product Name

Product Description

• Precise Valve Positioning Control: It adopts advanced digital control technology to ensure accurate valve positioning, improving the control accuracy of the process. It is suitable for the precise position control of regulating valves, electric valves, and pneumatic valves, achieving closed – loop control.
• High Reliability and Stability: With an industrial – grade design, it can adapt to harsh environments and has anti – interference capabilities, ensuring the long – term stable operation of the system. It uses high – quality electronic components, supports long – term continuous operation, and has a low maintenance cost.
• Compatibility with Ovation DCS Control System: As a standard module of the Ovation DCS system, it can be seamlessly integrated into the existing control architecture, improving the scalability and compatibility of the system. It connects to the host computer or other control units through standard communication protocols to achieve remote monitoring and adjustment.
• Fast Response and Optimal Control: It has high – dynamic response characteristics, which can quickly adjust the valve opening, improving the stability and efficiency of the production process. It supports adaptive control algorithms, optimizes the valve regulation performance, reduces system oscillation, and improves the process control quality.
• Easy Installation and Maintenance: With a compact modular design, it can be directly installed in the Ovation rack, simplifying the wiring and installation process. It adopts a hot – swappable design, supports online replacement, reduces downtime, and improves the maintainability of the system.
• Adaptability to Various Industrial Environments: It has a wide temperature range and can operate stably in different industrial environments. It adopts industrial – grade circuit protection to prevent faults such as voltage fluctuations and short – circuits, improving the system safety.

Product Parameters

• Communication Interfaces: Supports various industrial communication interfaces, such as MODBUS/ Slave, CCM Slave, and DNP3.0 Master/ Slave, and also supports user – defined protocols, facilitating seamless integration with PLC, DCS, and other systems2.
• Analog Input: Has 1 analog input channel, each channel has a 16 – bit resolution and an accuracy of ± 0.05%, which can provide reliable and accurate analog input signals2.
• Input Voltage and Current Range: The input voltage range is 0 – 10V, and the input current range is 0 – 20mA, suitable for a variety of voltage environments2.
• Supply Voltage: 24V DC2.
• Operating Temperature: – 20 °C to 60 °C2.
